HT190 Railway Vehicle Saloon Light with Ceiling Panel for Singapore Metro

Product Description

· Saloon light HT190 is designed for Singapore metro project, installed on the mid ceiling panel. It is a modular lighting system designed for direct illumination of the interior of public transport vehicles in Singapore.

· The Driver is integrated for power supply.

· Thanks to the variable length it is possible to create continuous lighting strip along the entire vehicle length.

· It provides soft and comfortable light.

· The lamp body is made of AL profile, which finished in powder painting surface treatment

· The light body profile and lamp cover are connected by hinge on one side, and on the other side are fixed together by screws;

· The light cover adopts laminated glass (complying with fire + smoke EN45545 HL2)

· The luminaire integrates the side roof and the valve access port

· With IP54 protection

· Salt spray test refer to ISO 11997-1:2017 Cycle B with 840h

· WAGO connector

· LED chipset: 2835

· Alternative LED light source

· Alternative color surface treatment

· Alternative customized dimensions

Product Specification

HT190 Railway Saloon Light

Singapore Metro Ceiling Light

Railway Vehicle Ceiling Panel

HT190 Railway Vehicle Saloon Light with Ceiling Panel for Singapore Metro Images
